Presto's Hot Wire Bottle Cutter is a widely used instrument in PET bottle industries. PET bottles are mainly used for packaging of various products such as carbonated drinks, food items and so forth. They are also used for packaging of chemical.

Model

PHWBC-NXG

Brochure


  • OVERVIEW

  • SPECIFICATIONS

  • FEATURES

  • VIDEO

  • REVIEWS

OVERVIEW

Presto’s Hot Wire Bottle Cutter is a widely used instrument in PET bottle industries. PET bottles are mainly used for packaging of various products such as carbonated drinks, food items and so forth. They are also used for packaging of chemical. The shape and size of the bottles is important for the better safety of the products that are packaged in the bottles. For the best shape and size, it is important to test the weight of every section of the PET bottles individually. This process is called the section weight analysis. For accurate section weight analysis, the individual sections of the PET bottles need to be cut properly and precisely without causing any deformation in the shape of the bottle. The Hot wire Bottle cutter helps in this testing procedure of the PET bottles.

The Presto’s Hot Wire Bottle cutter NXG is designed to easily cut the individual sections of the PET bottles. The capacity of the bottles that can be cut using the instrument ranges from 200 ml to 2000 ml. the maximum diameter of the bottles that can be cut with the hot wire bottle cutter is 110 mm. Each section of the bottles is cut in exact dimensions and not deformation occurs in the shape and size of the bottles during the cutting. After accurate cutting of the sections, each section is weighed on a digital balance for accurate measurement of the weight of the sections. This helps in controlling the manufacturing process for better quality assurance and quality control.

MATERIAL

INDUSTRY

SPECIFICATIONS

    • Sections cut: Top, Cylinder, Bottom
    • Display and control: Digital Heat
    • Bottle Neck Holder: 21.74 mm (Other Sizes available on request)
    • Heat Control: Variable through Port
    • Heating Method: Kanthal Element wire
    • Power: 220V, Single phase, 50 Hz
    • No.of wires: 2
    • Maximum Diameter of Bottle: 130 mm **
    • Maximum Cut length: min. 60 mm & Max. 320 mm
    • Other sizes available as per requirement
    • Heating levels: Low, Medium, High
    • Heat Monitoring: Digital Display
    • Material: Aluminum
    • Finish: Powder coated Havel Gray & Blue combination finish and bright chrome / zinc plating for corrosion resistant finish



FEATURES

    • Also known as section weight cutter.
    • A cost effective and efficient way of cutting sections of a PET bottle.
    • Best for accurate section weight analysis.
    • Strong clamping holder for zero slip gripping support
    • Digital Display of heating for accuracy and repeatability
    • Rapid heat up of wires for sample cutting
    • Precise measurement of test sample section weight analysis
    • Length, Width adjustable clamping mechanism to hold different size of bottles
    • Inbuilt with cutting wire tension adjustment
    • Equipped with Variable Voltage Potentiometer for heat control
    • Strong and rugged base plate
    • Available in 2-wire and 3-wire configuration
    • Adjustable fixture to test different size test bottles

VIDEO

REVIEWS


Cutting of bottles in three sections without affecting the edges now becomes easy task with Presto's Hot wire bottle cutter. the instrument is best for firm cutting. Thanks for the amazing product!!

— kirti deshpandey

The sharp and smooth cutting of the bottle produces highly accurate results. very much satisfied.

— Nirmal Pandey

Kanthal wire is considered to be the sharpest cutting wire of all. The equipment allow a smooth cut and slicing. Great testing results.

— Uday Gupta
