TP310 Portable Color Measurement

quick info

TP310 is a prominent color measurement instruments used in many mainstream industries which have been designed and manufactured by competent engineers and scientists of Testronix. The instrument has many advantages of other international standard color measurement instruments.

Model

TP310

Brochure


  • OVERVIEW

  • SPECIFICATIONS

  • FEATURES

  • VIDEO

  • REVIEWS

  • FAQ'S

OVERVIEW

TP310 is a prominent color measurement instruments used in many mainstream industries which has been designed and manufactured by competent engineers and scientists of Testronix. The instrument has many advantages of other international standard color measurement instruments. The product has undergone thousands of tests to provide affordable, accurate and stable testing to the customers.

The TP310 is a portable and high quality color measurement instruments works with color sensor with multiple channels of international standards. It is also provided with highly stable IC platform and an efficient algorithm that provides highly accurate and fast test results for color quality control management to the users. The instrument has an ergonomic design which facilitates easy operation of the equipment and has been applied on a number of other patents. It is a versatile and multifunction color measurement instruments which is easily available for the users at very competitive prices. The product has undergone thousands of tests to provide affordable, accurate and stable testing to the customers.

The portable color measurement instrument is used to measure the color consistency of various types of products and is designed for many production verticals like plastics, rubbers, paper & Packaging, paint & plating, automotive, textile and many more. The testing device is user-friendly and offers highly reliable and accurate test results. Presto Stantest is an authorized dealer of Testronix Instruments.

Check The Difference Between Different Models Of Testronix Products

MATERIAL

INDUSTRY

TEST

SPECIFICATIONS

    • Illumination/Observation system: 8/d (8º illumination angle/diffuse viewing)
    • Measuring Aperture: 8 mm, 4 mm (Diameter)
    • Optional: 8 mm (Diameter) extended aperture
    • Light Sources: LED blue light excitation, D65, and D50A
    • Detector: Silicon photoelectric diode
    • Color Spaces Indices: Yellowness & Whiteness color fastness CIEL*a*b*C*h* CIEL*a*b* CIEXYZ CIERGB CIEL*u*v* CIEL*C*h
    • Minimum Interval Between measurement: Approx 1.0 s
    • Measuring range: L:0 to 100
    • The instrument comes with a storage capacity of 20000 samples and 100 standards.
    • The test procedure with this instrument can be repeated with a maximum allowable deviation under ΔE*ab 0.06
    • The power source for the instrument is a li-ion battery with a capacity of 3200mAh and 3.2 volts that is rechargeable.
    • Another optional accessory that comes with the instrument is Miniature thermal printer.
    • color difference formulas: △E*ab △L*a*b* △E*C*h* △ECIE94 △Ehunter Communication: USB/RS 232

FEATURES

    • Adopts accurate camera locating feature
    • Illumination locating for user ease of operation
    • Software based output of test results
    • Auto white and black calibration
    • Various Color Sources
    • Display of Whiteness, Yellowness, and Color Fastness
    • Provides highly convenient operation and has an ergonomic design.
    • The measurement and performance of the instrument are highly repeatable and stable.
    • With computer software given with the instrument, the functionality of the instrument can be expanded extensively.
    • The instrument also has a highly advanced design for power management.
    • Standards: CIE

VIDEO

REVIEWS


I have purchased portable color measurement instrument for our food processing industry to maintain the color consistency throughout the process of prodcution and it really worked for us. Credit goes to Presto for providing the best product &to Testronix as well for the wonderful creation.

— Suniti Pandey

I make promotional material for big brands and despite having computer aided colour matching, there comes a disparity in the final print of the product. Due to surface texture, there are visible differences. TP 310 helped my colour managers to make prints cent percent accurate.

— Prakash Mitra Sharma

FAQ'S

Who do I contact for domestic sales? -

You may contact us by filling up the online form on our website or you may call us on +91 129 4272727 and talk to our marketing team, we are open from Monday to Saturday 10 am to 6 pm IST. You may also mail us at [email protected] we would respond to your online request within 1 working day.
