Vacuum Leak Tester Digital - ECO Model

quick info

Vacuum Leak Tester Digital Eco is an economic and proficient testing device that adds quality control measures to your packaging applications. It is utilized for inspecting any sort of leaks in a variety of packaging for foiled cups, gels, grains, cereal, bakery products, confectionery items, frozen foods, cheese, medical and pharmaceutical products, etc.

Model

PVL - 0130 (150 mm)

Brochure


  • OVERVIEW

  • SPECIFICATIONS

  • FEATURES

  • VIDEO

  • REVIEWS

OVERVIEW

It also complies with various national and international testing standards such as, ASTM F 2338-09(2013), ASTM D 4991-07(2015) and ASTM D6653.

How it works:
The Presto leak detector and seal integrity testing unit is a high-quality machine that consists of a clear acrylic vacuum chamber and system, a control valve, and an indicator gauge. Packages to be tested are simply placed in the clear acrylic vacuum tank, the lid is closed and vacuum engaged. You can then choose which testing method to use based on your company’s standards and requirements. A complete test can be accomplished in just a matter of seconds with immediate results!

Testing Standards (Methods):
ASTM F 2338-09(2013) – Non-destructive Detection of Leaks in Packages by Vacuum Decay Method.
ASTM D6653 - Test methods for determining the effects of high altitude on packaging systems by vacuum method.
ASTM D 4991-07(2015) – Destructive Leak integrity test by vacuum method for empty rigid containers. Leaks are detected under differential pressure conditions.

Testing Specimen Types:
Stand-up pouches, packages with modified atmosphere packaging (MAP), rigid trays, vacuum skin packs, thermoform packages, sachets, flow wraps, form fill seal (VFFS) and reclosable packages.

INDUSTRY

TEST

SPECIFICATIONS

    • Vacuum adjustable up to – 900 mb (675 mm-Hg.)
    • Box made of polished transparent PMMA (very rugged)
    • Easy to use and safe
    • 2 stage vacuum and holding time setting
    • Accuracy: 0.5% of the measure
    • Delivered with vacuum generator
    • Customised Box with dimensions upon request

FEATURES

    • Offers accurate and reliable results.
    • Strictly complies with international quality standards.
    • Provided by a calibration credential acceptable to NABL approved labs.
    • Microprocessor-based for accuracy and repeatability
    • Meets USP 28 Packaging Practice specification
    • Automatic sample testing through easy vacuum mechanism
    • Pressure, Inlet Vacuum Pressure setting, and Pre-set Timer function incorporated
    • Changeable Timer Units in Hrs:min:sec
    • Digital Pressure displays for easy pressure monitoring
    • Stainless steel and powder coated body for corrosion resistant finish

VIDEO

REVIEWS


With the help of vacuum leak tester provided by Presto, we can now test the quality of the products with best efficacy and accuracy. The instrument is very easy to use and is best for our packaging industry.

— Shravan Miglani

This is the third testing instrument that I have bought from Presto and not to my surprise, their service is amazing like the first time. I am definitely now a loyal customer of this company.

— Kuldeep Sardesai
