Pouch Compression Tester NXG

Presto Stantest, a trusted pouch compression test supplier, delivers precise pouch compression strength testing with an advanced touch panel HMI and high-speed controller. Featuring built-in power and communication isolation, it ensures accurate, noise-free results with ± 0.5% accuracy. Supporting force, displacement, and time-based test methods, this compression testing machine is ideal for quality control labs in packaging and pouch manufacturing industries.

Video

The Pouch Compression Tester – NXG Generation Model from Presto Stantest Pvt. Ltd. upgrades our standard compression tester with a powerful HMI touch panel and advanced protective circuitry. It determines pouch compression strength by placing the sample on a flat platform and applying a controlled downward force via a motorized arrangement.

Built-in power isolation and isolated COM/Ethernet interfaces protect against voltage spikes and electrical noise from PLCs, motor drives, and inverters. The instrument supports force, displacement, and time-based test methods, delivering accurate, repeatable results through a high-speed controller. Additional features include TARE and peak hold, over-travel/load protection, PDF reporting, a pre-load facility, and an optional printer—with computerized models and multiple platform/load cell configurations also available.

7" TFT LCD colour screen
± 0.5% full-scale (with master load) accuracy
220V, Single / Three phase, 50 Hz
Test Speed: 12.5 ± 2.5 mm/min
Results / Report: 10 samples max and average
Displacement Least Count: 0.1 mm
Platform Size: 750 x 750 mm
Material: Mild Steel
Finish: Powder-coated Havel Gray & Blue combination with bright chrome/zinc plating for corrosion resistance
Pre-load Function: Programmable as per user-defined inputs.

Advanced Touch Panel Interface—Large capacitive touchscreen with 7" TFT LCD color display for intuitive, HMI-based operation.
Robust Isolation Protection – Built-in power isolation circuits plus isolated COM and Ethernet interfaces guard against voltage spikes and electrical noise from PLCs, motor drives, and inverters.
Multiple Test Methods—Choose between force-, displacement-, or time-based testing, backed by a high-speed controller for accurate, repeatable results.
TARE, Peak Hold and Safety Protection—It automatically records maximum test values in memory, with upward and downward limit switches for over-travel and overload protection
PDF Reporting and Trend Graph—It can quickly create PDF test reports and show load versus displacement data in a visual way for detailed analysis.

For queries like pouch compression tester price, contact Presto Stantest at +91 9210 903 903 or info@prestogroup.com

Q: Are computerized models and different platform sizes available?
A: Yes, computerized models are available for the Presto Pouch Compression Testing Machine, along with various platform sizes and load cell capacities to suit different testing requirements.

Q: Does the instrument support reporting and data analysis?
A: Yes, it offers PDF test report generation, an optional printer facility, and a trend graph displaying load vs. displacement data for detailed analysis.

Q: What safety and protection features are built into the machine?
A: The tester has switches that stop it from moving far up or too far down. This helps prevent damage from much movement or too much weight. It also has power and communication lines. These lines are protected so they do not get hurt by spikes of electricity or other noisy signals. The tester includes these things to keep it safe.

Q: What test methods and accuracy does this instrument offer?
A: It supports force, displacement, and time-based test methods, with an accuracy of ± 0.5% of full scale, measured with a master load.

Q: What is the Pouch Compression Tester NXG Generation Model used for?
A: It is used to determine the compression strength of pouches by placing the sample on a flat platform and applying a controlled downward compressive force through a motorized arrangement.
